Zastosowanie:
Makita: DDF482, DHP482
Lista części od DDF482
1 851E35-2 DDF482 NAME PLATE 1
2 183B65-0 HOUSING SET 1
2 C10 263005-3 RUBBER PIN 6 2
2 D10 INC. 22
3 266429-2 TAPPING SCREW 3X16 9
4 123442-2 SPEED CHANGE LEVER ASSEMBLY 1
4 C10 233438-6 COMPRESSION SPRING 4 2
5 419041-9 F/R CHANGE LEVER 1
6 650753-7 SWITCH C3HA-Z1A-TLF1MS 1
6 C10 620444-4 LED CIRCUIT 1
7 251468-5 - FLAT HEAD SCREW M6X22 1
8 766027-7 KEYLESS DRILL CHUCK 13 1
9 123444-8 GEAR ASSEMBLY 1
009-1 127323-2 GEAR ASSEMBLY 1
009-2 127511-1 GEAR ASSEMBLY 1
10 632F32-1 YOKE UNIT 1
010-1 632J70-7 YOKE UNIT 1
11 619380-9 ARMATURE 1
12 632F22-4 BRUSH HOLDER COMPLETE 1
12 D10 INC. 13
13 194427-5 CARBON BRUSH SET CB-440 1
14 456099-7 REAR COVER 1
15 266429-2 TAPPING SCREW 3X16 2
16 911006-2 PAN HEAD SCREW M3X8 1
016-1 652066-2 +PAN HEAD SCREW M3X9 WITH W 1
17 689070-8 HEAT SINK 1
18 232182-2 LEAF SPRING 1
19 644808-8 TERMINAL 1
22 183B65-0 HOUSING SET 1
22 C10 263005-3 RUBBER PIN 6 2
22 D10 INC. 2
A01 251314-2 + SCREW M4X12 1
A02 346317-0 HOOK 1
A03 784637-8 +- BIT 2-45 1
A04 141856-3 PLASTIC CARRYING CASE COMPLETE 1
A04A C10 162302-3 LATCH 2
A04A C20 324207-7 SHAFT 1
A04A C30 451749-9 HANDLE 1
A05 450128-8 BATTERY COVER 1
A06 ***DC18RC DC18RC FAST CHARGER 1
A07A 196399-0 BATTERY BL1840 SET 2
A07-1A 197265-4 BATTERY BL1840B SET 2
A07-1C 194204-5 BATTERY BL1830 SET 2
A07-2A 197265-4 BATTERY BL1840B SET 2
A07-2C 197600-6 BATTERY BL1830B SET 2
A07-3C 197600-6 BATTERY BL1830B SET 2
A08A 807S73-6 DDF482RME PLASTIC CASE LABEL 2
A08C 808N51-9 DDF482RFE PLASTIC CASE LABEL 2
